Gel fudge production line
Equipment Introduction:
The production line is developed by the R & D department of our company according to the market demand for various shapes and colors of gel soft candy, using advanced production technology. It is an ideal equipment for continuous production of high-grade colloidal candy (QQ candy). Can produce high-quality single-color, two-color QQ sugar; can also be replaced by mold or casting head to produce high-quality, a variety of shapes, a variety of colors of gel jelly. The quantitative filling and mixing of flavor pigment acid is completed online; highly automated production can not only produce products with stable quality, but also save manpower and space, thus reducing production costs.
Process flow:
Soluble sugar →Filtration→boiled sugar→Cooling→Additive→pouring molding→Cooling→Demoulding→Drying room→Packaging→ Packing
Technical parameters:
|
Model |
JYJ-150 |
JYJ -300 |
JYJ -450 |
JYJ -600 |
|
Standard output (kg/h) |
150 |
300 |
450 |
600 |
|
Maximum sugar weight (g) |
2~8 |
2~8 |
2~8 |
2~8 |
|
Pouring speed (n/min) |
55~65 |
55~65 |
55~65 |
55~65 |
|
Working environment requirements |
Temperature 20~25 ℃, humidity 55% |
|||
|
Overall power |
32KW/380V |
39KW/380V |
48KW/380V |
75KW/380V |
|
Length of whole line (M) |
17 |
17 |
18 |
18 |
|
Overall weight (kg) |
3000 |
3500 |
4000 |
4500 |
