Toffee pouring production line

JYT150 ~ 600 toffee production line automatic candy production line candy machine candy processing equipment

Keywords:

Candy Machinery Series

Product Classification:

Candy Machinery Series

Telephone:

17317215245

Message

Details Introduction

Toffee pouring production line

Equipment Introduction:

1) the use of international brand PLC, more stable performance, programming automatic control of vacuum boiling sugar temperature, time, holding temperature and pouring speed;

2) The 10.7-inch large touch screen displays the process flow chart, the working status of each part, the setting and display of parameters such as temperature and pouring speed, making it easier for users to operate and master;

3) The production capacity of this series of products can be from 150kg to 600kg per hour;

4) The accurate flow rate of sugar liquid is controlled by frequency conversion speed regulation, and the quality of sugar paste is stable;

5) The dynamic mixer completes the quantitative filling and mixing of essence, pigment and acid on-line;

6) Conveyor chain belt, cooling system and double demoulding mechanism ensure demoulding;

7) according to the different mold can produce various shapes of candy;

8) Optional chocolate timing filling system can produce chocolate sandwich candy;

9) Replace some devices and molds. This production line can produce spherical and flat three-dimensional lollipops.

Technical parameters:

Model	JYT-150	JYT-300.	JYT-450.	JYT-600.
Standard output (kg/h)	150	300	450	600
Maximum sugar weight	6	6	6	6
Pouring speed (n/min)	55~65	55~65	55~65	55~65
Steam demand	250kg/h 0.5~0.8MPa	300kg/h 0.5~0.8MPa	400kg/h 0.5~0.8MPa	500kg/h 0.5~0.8MPa
Compressed air demand	0.2m³/min 0.4~0.6MPa	0.2m³/min 0.4~0.6MPa	0.25m³/min 0.4~0.6MPa	0.25m³/min 0.4~0.6MPa
Working environment requirements	Temperature 20~25 ℃ Humidity 55%	Temperature 20~25 ℃ Humidity 55%	Temperature 20~25 ℃ Humidity 55%	Temperature 20~25 ℃ Humidity 55%
Overall power	32KW/380V	39KW/380V	48KW/380V	75KW/380V
Length of whole line	17	17	18	18
Weight of whole machine	3500	4000	4500	5000
